2–8

c

Chapter 2: Getting Started

MegaWizard Plug-In Manager Design Flow

Turning off the Display entity name for node name setting prevents the

timing analysis script from completing successfully. To enable this setting,

open the Assignments menu and click Settings . On the Settings page, click

Compilation Process Settings, and then click More Settings . In the Name

list, select Display entity name for node name and in the Setting list, select

On .

The results show how much slack you have for each of the various timing

requirements—negative slack means that you are not meeting timing. The Message

window shows various timing margins for your design.

If the verify timing script reports that your design meets timing, you have

successfully generated and implemented your DDR or DDR2 SDRAM Controller.

If the timing does not reach your requirements, adjust the resynchronization and

postamble clock phases on the IP Toolbench Manual Timings tab (refer to “Manual

Timing Settings” on page A–1 ).

f

1

f

For more information on how to achieve timing, refer to Appendix B, DDR SDRAM

on the Nios Development Board, Cyclone II Edition .

To view the constraints in the Quartus II Assignment Editor, choose Assignment

Editor (Assignments menu).

If you have “?” characters in the Quartus II Assignment Editor, the Quartus II

software cannot find the entity to which it is applying the constraints, probably

because of a hierarchy mismatch. Either edit the constraints script, or enter the correct

hierarchy path in the Hierarchy tab (refer to step 24 on page 2–13 ).

For more information on constraints, refer to “Constraints” on page 3–18 .

Program a Device

After you have compiled the SOPC Builder design, you can perform gate-level

simulation (refer to “Simulate the SOPC Builder Design” on page 2–6 ) or program

your targeted Altera device to verify the SOPC Builder design in hardware.

With Altera's free OpenCore Plus evaluation feature, you can evaluate the DDR or

DDR2 SDRAM controller MegaCore function before you purchase a license.

OpenCore Plus evaluation allows you to produce a time-limited programming file.

f

For more information on OpenCore Plus hardware evaluation using the DDR or

DDR2 SDRAM controller MegaCore function, refer to “OpenCore Plus Evaluation”

on page 1–6 , “OpenCore Plus Time-Out Behavior” on page 3–3 , and the AN 320:

OpenCore Plus Evaluation of Megafunctions .

MegaWizard Plug-In Manager Design Flow

MegaWizard Plug-In Manager design flow involves the following steps:

1. Create a custom variation of the DDR or DDR2 SDRAM controller MegaCore

function using IP Toolbench from the MegaWizard Plug-In Manager.

DDR and DDR2 SDRAM Controller Compiler User Guide

? March 2009 Altera Corporation
